The security features provided by the 303 Deadlock make it an ideal lockset for both domestic and commercial applications.

Satin Chrome Pearl Only

Features of the 303 Deadlock

Suitable for hinged and some sliding doors
Lockable turn knob with inbuilt clutching device to resist wrench attack
Strong interlocking case and mounting plate to resist jemmy and hammer attack
Tested in accordance with AS4145.2-1993
Concealed fixing
Positive deadlocking action
The mechanism and the design are protected by Australian and International Patents and Design Registrations
Available in trade and display pack versions
Opened by key from outside and by turn knob from inside.

Kinetic Defence
Bump and pick resistant.

2 Keys Included
Can be keyed alike to other Lockwood door locks.

Case

Thick walled, high purity zinc alloy casting
121mm wide, 76mm high, 56mm projection

Backset

60mm.

Bolt

Stainless steel.

Mounting Plate and Strike

Pressed steel.

Case Retainer Plate and Operating Mechanism

Solid pressed steel and diecast
Zinc components

Packing Plates

3mm thick packing plates installed under lock body to align lock body with face of jamb.

Strike Conversion Plate

A strike conversion plate is required where the strike is to be installed in place of an existing flange strike.

Door Thickness

30 – 45mm.

Cylinders

5 pin tumbler mechanism outside
Brass cylinder and barrel

Keying

Standard Keying

Supplied individually keyed with two keys per lock
78,000 key combinations
Key blank KB2015P

Restricted Special Keying

Lockwood locks can be keyed to a number of controlled and/or specially keyed systems.
These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

Lockwood Keying Platforms - more information

Finish

Satin Chrome Pearl SP
